Description
Simkar 6600012 4.8 Volt Nicad Replacement Battery
The Simkar 6600012 is a high-reliability 4.8-Volt Nickel-Cadmium (Ni-Cd) battery pack used in Simkar emergency lights and exit signs. Built from four matched 1.2V cells in series, it delivers stable standby power, fast recharge, and long cycle life to keep life-safety fixtures compliant.
Key Features
- Direct replacement for Simkar part 6600012.
- Ni-Cd chemistry for dependable backup in varied temperatures.
- Industrial assembly: spot-welded tabs, insulated wrap, strain-relieved leads.
- Fresh inventory for maximum service life and runtime.
- Replaces Danota CUSTOM-43 OSI OSA126 Interstate NIC0186 Cameron Sino CS-EMC487LS Anybattery 8423 BCN800-4EWP-CE623RP
Common Applications
- Simkar emergency lighting fixtures
- Exit signs / combo units specifying 4.8V Ni-Cd
- Other OEM devices calling for a 4-cell 4.8V pack
Specifications
| OEM / Reference | Simkar 6600012 |
|---|---|
| Nominal Voltage | 4.8 VDC (4 × 1.2V in series) |
| Capacity (typical) | Model-dependent; 900 mAh |
| Chemistry | Nickel-Cadmium (Ni-Cd), rechargeable |
| Configuration | 4-cell pack (inline “stick” or 2×2 block varies by fixture) |
| Terminations | Lead wires / OEM connector (JST/Molex styles are common) |
| Operating Temp | Approx. −20 °C to +50 °C (device-dependent) |
| Compliance | Non-spillable; suitable for typical e-light code testing |
Fit & Verification
Before ordering, match the following from your original battery or fixture:
- Part number: 6600012 (or cross-reference on label)
- Pack layout (stick vs. 2×2 block), dimensions, and mounting space
- Connector type/pinout and lead length; polarity orientation
- Capacity marking (900 mAh) if your maintenance plan requires like-for-like
What’s Included
- (1) 4.8V Ni-Cd battery pack replacing Simkar 6600012 (connector/leads per listing)
Installation & Maintenance
- Disconnect AC power and follow lock-out procedures.
- Note connector orientation and polarity; remove the old pack.
- Install the new pack; fully seat the connector and secure wiring.
- Restore AC and allow 24 hours for a full charge, then run a 90-minute test.
Service tip: Record install date and next test in your safety log to simplify inspections.
Shipping & Availability
Ships quickly from U.S. warehouses. Contractor and volume pricing available.
