Description
3B50 Lithium Thionyl Chloride cell solders in or plugs into a socket.
High energy, high reliability 3.6 volt power source.
Maximum continuous current 1.0mA.
Low self discharge rate gives this cell a 10 year shelf life.
Stable voltage and broad temperature range (-40° to +85°C).
Replaces:
| 3B0050 3B6050 6135-01-324-4692 6135013244692 BCX72 BCX72 3B0050 BCX72 3B50 BCX72 PC BCX72-3B0050 BCX72-3B50 |
BCX85 BCX85 3B0050 BCX85 3B50 BCX85 3B6050 BCX85 PC BCX85-3B0050 BCX85-3B50 BCX85-3B6050 NSN: 6135-01-324-4692 |
Assembled in the USA
| Type: | Lithium |
| Voltage: | 3.6 |
| Capacity: | 1000 mAh |
| Color: | Silver & Blue |
| Size: | 1.00″ diameter x 0.297″ tall |
| Contacts: | 3 PC Pins |
| Warranty: | DOA |
